Surface Roughness Tester with Printer-CWR-209-RTZ

POINTVALUES CWR-209-RTZ Surface Roughness Meter with Printer

The advanced portable Surface Roughness Tester is suitable for measuring surface roughness on hard surfaces, widely used for both metal and non-metal parts in machining, manufacturing, testing, and inspection as part of quality control. It allows on-site measurement for a wide range of items from production lines, as well as for mobile inspection. The measurement is non-destructive, ensuring no damage to the items under inspection.

Features

• Mechatronics design
• Embedded printer to include graphics
• External control unit allows measurement in any direction: sideways, upward, or as needed
• 320μm measuring range (640μm option available)
• 3.5-inch LCD tactile screen with brightness and wide viewing angle
• Duplicate physical buttons in addition to tactile screen operation
• Intuitive display with all parameters and graphics
• Compatible with ISO, DIN, ANSI, JIS, and many national standards
• Rechargeable lithium-ion battery with charging control circuit and indicator; lasts up to 50h per charge
• Large internal memory: stores up to 100 sample data sets
• Real-time display of results
• Clock setting and display
• Automated sleep, shutdown, and power-saving functions
• Reliable circuit and software design to prevent motor jamming
