Portable Density, Concentration and Thermo Meter- PB- M23-180CT

POINTVALUES Portable Density, Concentration and Thermo-Meter – PB-M23-180CT

Model: PB-M23-180CT

Description: Facilitates liquid density and temperature measurements with high accuracy.

Applications

• Characterizes alcohols, sugar solutions, foods, beverages, dyes, additives, biological fluids, micelles, colloidal solutions, acids, solvents, and mixtures of various viscosities.
• Customizable concentration formulas.
• Uses U-tube oscillation principle for density measurement via resonance frequency detection.

Key Features

• 2.4-inch color HD display.
• Ergonomic design for single-hand operation.
• Stores up to 1000 data points.
• Data transfer via USB, Wi-Fi, Bluetooth, and NFC.
• Supports wireless Bluetooth printing.
• Sample ID input via code scanning and NFC.
• Quartz glass and PTFE probe for corrosion resistance.
• Quick-release syringe pump for cleaning and replacement.
• Built-in pure water and air calibration.
• Automatic density and relative density compensation.
• Operates on very small sample volume.
• Built-in suction pump (1.0–2.3 mL).

Application Areas

• Chemical industry
• Food and beverage
• QC laboratories
• Industrial and environmental fields
• Chemical R&D
• Petroleum industry
• Pharmaceutical and medical sectors

Technical & Functional Features – Testing Parameters

1. Density Measurement

• Range: 0.0001 ~ 3.0000 g/cm³
• Resolution: 0.0001 g/cm³
• Accuracy: 0.001 g/cm³
• Repeatability: 0.0005 g/cm³

2. Temperature Measurement

• Range: 0.0 ~ 50.0 °C
• Resolution: 0.1 °C
• Accuracy: ±0.2 °C
• Repeatability: 0.1 °C

3. General Parameters

• Wireless thermal printer (optional, 55×30 mm roll)
• Code scanner & RFID/NFC support
• Storage: 1000 data records
• Operating temperature: 0°C–50°C
• Operating humidity: 0–80% RH
• Altitude limit: below 2000 meters
• Storage temperature: 0–40°C
• Storage humidity: 0–50% RH
• Battery: 3.7V / 3000mAh lithium-ion
• Power supply: 5V 2A adapter
• Dimensions: 150 × 57 × 271 mm
• Weight: 350g

Contents of the Unit Pack

1. Densitometer main unit
2. Power adapter
3. USB-C cable
4. USB-OTG cable
5. 2x Teflon straws (with fittings)
6. 3x density calibration standard solutions
7. User manual (hard copy)
8. Warranty card (hard copy)
9. Bluetooth printer paper roll (optional)
10. NFC Smart Labels (optional)

Important Notes

• Charge the instrument at least once every six months.
