Portable Combustible Gas Leak Detector- CSG-LY3-L04

POINTVALUES Portable Combustible Gas Leak Detector – CSG-LY3-L04

The CSG-LY3-L04 is a high-precision safety device designed for continuous monitoring of combustible gas concentrations. It features advanced integrated circuit technology, adheres to international intelligent design standards, and employs proprietary digital-analog hybrid communication technology. The detector uses a flexible gooseneck probe for gas detection via natural diffusion and is equipped with premium imported sensors for exceptional sensitivity and repeatability.

This detector can monitor a variety of combustible gases, including methane, natural gas, hydrogen, coal gas, acetone, gasoline, ethanol, oxides, sulfides, alcohols, and other organic vapors.

Technical and Functional Features

• 2.3-inch LCD display
• Measurement Range: 0–10,000 ppm
• Resolution: 1 ppm
• Specific for combustible gases: methane, propane, natural gas, liquid alkanes
• Detection rate: 1 mmol/min
• Maximum detection: 2000 µmol
• Accuracy/Resolution: ±5% FS
• Working Pressure: -30–200 KPa
• Operating Temperature: -20–50°C
• Adjustable unit: mol/µmol
• Maximum Relative Humidity: 95%
• Powered by 1800 mAh Al battery
• Dimensions: 68 × 26 × 180 mm
• Weight: 180 g
• High protection level: IP65 standard
