POINTVALUES ULH-E50-XC6 ultrasonic homogenizer
$0.00
ULH-E50-XC6 ultrasonic homogenizer integrates network control and remote printing, aligning with modern, user-friendly design principles.
To enhance biological safety, the device features an ultraviolet sterilization function, reducing the risk of personnel infection and sample cross-contamination.
It accommodates sample processing of various volumes, with corresponding models and probes available to suit different needs. This versatile product is widely utilized for sample disruption, emulsification, homogenization, and crushing across life sciences, pharmaceuticals, and materials chemistry.
ULH-E50-XC6 Ultrasonic Homogenizer
ULH-E50-XC6 ultrasonic homogenizer integrates network control and remote printing, aligning with modern, user-friendly design principles.
To enhance biological safety, the device features an ultraviolet sterilization function, reducing the risk of personnel infection and sample cross-contamination.
It accommodates sample processing of various volumes, with corresponding models and probes available to suit different needs. This versatile product is widely utilized for sample disruption, emulsification, homogenization, and crushing across life sciences, pharmaceuticals, and materials chemistry.
Main Features:
- High Safety: Equipped with over-temperature, overload, and time alarm functions, user password protection, UV sterilization, and door lock features.
- User-Friendly Interface: External transparent front door and built-in LED lighting provide clear visibility of the process.
- Program Storage: Capable of storing up to 20 sets of operating procedures.
- Space-Saving Design: Vertical stacking configuration optimizes laboratory space.
- Flexible Parameters: Ultrasonic time and power are continuously adjustable, ensuring high stability.
- Remote Control Capability: The system includes a remote monitoring communication interface, enabling network control and remote printing.
- Electric Lift: The base position is adjustable via electric lift, eliminating manual handling.
- Wide Application Range: Various models can accommodate the needs of different users and sample volumes.
Technical Parameters
| Model | ULH-E50-XC6 |
| Power | 6.5–650 W adjustable |
| Mixing capacity | 0.1–500 ml |
| Display | 7 inch Touch Screen |
| Single ultrasonic time | 0.1–99.9 s |
| Ultrasonic gap | 0.1–99.9 s |
| Total working time | 1 min–99 H 59 M 59 S |
| Frequency | 20–25 kHz |
| Temperature Control | 0–100 ℃ |
| Alarm function | Temperature, time, overload, no load, over temperature |
| Optional Horns | 2 / 3 / 6 / 8 / 10 / 12 mm |
| Standard Horn | 6 mm (suitable for 10–100 ml capacity) |
| Data Storage | 20 sets |
| Voltage | 220 V / 110 V, 50 Hz / 60 Hz |
| Ultrasonic Host Dimension | 427 × 340 × 168 mm |
| Ultrasonic Host Weight | 11 kg |
| (Ultrasonic horn + Transducer) Weight | 2 kg |
| Ultrasonic Host Packing Dimension | 500 × 400 × 320 mm |
| Soundproof Box Packing Dimension | 320 × 320 × 520 mm |
| Soundproof Box Weight | 13 kg |
| Working voice alarm & Fault indication | Supported |
| Ultrasonic time pulse width data | Supported |
| Ultrasonic power simulation data | Supported |
| Password protection function | Supported |
| Ultrasonic host material | Aluminum alloy + ABS |
| Soundproof box material | Anti-corrosive + ABS |
| Soundproof box chamber inside lighting | Yes |
| Soundproof box sterilization | Yes |
| Remote electric lifting | Yes |
